The Legacy Reimagined
Honoring the great names of the past—Voigt, Jensen, Klangfilm—the AC-X reinterprets the heritage of electric magnet drivers with a visionary new approach. At its heart lies a completely re-engineered field coil system, developed by Voxativ to meet the demands of modern high-resolution audio while preserving the warmth and depth that made these historic designs so beloved.
This is not nostalgia. It is evolution.
The AC-X delivers a dynamic range and tonal fullness that feels almost analog in nature—rich, immediate, and deeply involving. Whether in a finely crafted backloaded horn or a revealing open baffle design, this driver unveils a soundstage that is vast, dimensional, and emotionally present.
Specification
Frequency Response:
20 – 20,000 Hz
Efficiency (at 12V field voltage):
105 dB / 2,83V / 1m
Power Handling:
50 W nominal / 100 W musical
Impedance:
10.5 Ohms
Qts (at 12V):
0.35
Mounting Depth:
6.5 in / 16.5 cm
Outer Diameter:
7.5 in / 19 cm
Weight:
12.0 kg / 27 lbs
LEAD TIMES // Upon payment, products are then assembled and packed with a typical lead time of 10 days for drivers, and 3 weeks for loudspeakers and field coil drivers.
